Chillers · Open Type
Open Type Chiller 1250
1,250 mm open multideck with air curtain for grab-and-go dairy, juice and fresh.
Model code: EOC-1250Energy class: C
- Gross capacity
- 900L
- Temperature range
- 2…5°C
- Annual energy consumption
- 2,890kWh/year
- Warranty
- 60mo
The cabinet
Overview
An open-front multideck for supermarkets and grab-and-go counters where a door would slow the shopper down. A tuned honeycomb air curtain holds 2–5 °C at the front of each shelf, and a pull-down night blind cuts overnight consumption when the store closes.
- Doors
- 0
- Refrigerant
- R290
- Dimensions (W × D × H)
- 1250 × 780 × 2000 mm
- Net capacity
- 820 L
- Climate class
- 3 (25 °C / 60% RH)
- Warranty
- 12/60 mo
Annual consumption measured over a standard 24-hour duty cycle at 25°C ambient.
Features and benefits
- 01No door between shopper and productOpen access lifts grab-and-go conversion for dairy, juice and ready meals.
- 02Honeycomb air curtainA laminar curtain holds product temperature at the shelf edge, not just at the back wall.
- 03Night blind as standardClosing the blind after hours cuts overnight energy draw by up to 30%.
Technology in this model
- Full-height LED illuminationVertical LED bars lift shelf-level brightness while drawing a fraction of a fluorescent load.
- R290 hydrocarbon refrigerantLow-GWP charge in series production, more than 99% below an equivalent R404A circuit.
- Digital controllerLockable set point with fault-code readout for first-line diagnosis before a visit is booked.
Full specification
Specifications are nominal and measured at 25°C ambient. Tolerances and market-specific variants are confirmed on quotation.
Capacity & dimensions
| Gross capacity | 900 L |
|---|---|
| Net capacity | 820 L |
| Dimensions (W × D × H) | 1250 × 780 × 2000 mm |
| Net weight | 196 kg |
| Doors | 0 doors |
| Shelves | 5 adjustable wire shelves |
Energy & lighting
| Energy class | Energy class: C |
|---|---|
| Annual energy consumption | 2890 kWh/year |
| Lighting | LED canopy and full-height side LED |
Cooling system
| Refrigerant | R290 |
|---|---|
| Temperature range | 2 … 5 °C |
| Climate class | 3 (25 °C / 60% RH) |
| Defrost | Automatic, controller-timed |
| Controller | Digital controller with lockable set point |
Power & support
| Power supply | 220–240 V / 50 Hz |
|---|---|
| Noise level | 45 dB(A) |
| Warranty | 12 / 60 months |
Request a quote for this model
Your inquiry arrives pre-filled with this model name and code, so nothing is lost in translation.
Open Type Chiller 1250 · EOC-1250
