Visi Cooler 400

The volume single-door cooler: 400 L, five shelves, convenience-store footprint.

Model code: EVC-400Best sellerEnergy class: A

Gross capacity
400L
Temperature range
1…10°C
Annual energy consumption
684kWh/year
Warranty
60mo
Request a Quote

The cabinet

Overview

Our highest-volume single-door model and the default specification for convenience rollouts across the Gulf. Five adjustable shelves take standard bottle and can formats without wasted pitch, and the cabinet is rated for 43 °C ambient in Gulf specification.

Doors
1
Refrigerant
R290
Dimensions (W × D × H)
620 × 650 × 1980 mm
Net capacity
371 L
Climate class
4 (30 °C / 55% RH) · Gulf option 43 °C / 65% RH
Warranty
12/60 mo

Annual consumption measured over a standard 24-hour duty cycle at 25°C ambient.

Features and benefits

  1. 01Built around real pack formatsShelf pitch is set for 330 ml cans and 1.5 L bottles without leaving a dead band above the product.
  2. 02Gulf-specification glazingDouble-glazed low-E door with perimeter heating prevents condensation at 65% relative humidity.
  3. 03Serviceable from the frontCondenser and fan are reachable without pulling the cabinet out of the run, which keeps service visits short.

Technology in this model

  • EMMD demand-matched controlCompressor speed tracks real cooling load, returning up to 20% energy savings against a fixed-speed unit.
  • Full-height LED illuminationVertical LED bars lift shelf-level brightness while drawing a fraction of a fluorescent load.
  • R290 hydrocarbon refrigerantLow-GWP charge in series production, more than 99% below an equivalent R404A circuit.
  • Low-E double glazingHeated perimeter glazing keeps the door clear at 65% relative humidity, so product stays visible.
  • Keyed door lockFitted as standard for unattended, staff-area and overnight placement.

Full specification

Specifications are nominal and measured at 25°C ambient. Tolerances and market-specific variants are confirmed on quotation.

Request a QuoteDownload ManualDownload Brochure

Capacity & dimensions

Visi Cooler 400 EVC-400 — Full specification — Capacity & dimensions
Gross capacity400 L
Net capacity371 L
Dimensions (W × D × H)620 × 650 × 1980 mm
Net weight91 kg
Doors1 door
Shelves5 adjustable wire shelves

Energy & lighting

Visi Cooler 400 EVC-400 — Full specification — Energy & lighting
Energy classEnergy class: A
Annual energy consumption684 kWh/year
LightingLED canopy and full-height side LED

Cooling system

Visi Cooler 400 EVC-400 — Full specification — Cooling system
RefrigerantR290
Temperature range1 … 10 °C
Climate class4 (30 °C / 55% RH) · Gulf option 43 °C / 65% RH
DefrostAdaptive, demand-triggered
ControllerEMMD demand-matched digital controller

Power & support

Visi Cooler 400 EVC-400 — Full specification — Power & support
Power supply220–240 V / 50 Hz
Noise level43 dB(A)
Warranty12 / 60 months

Request a quote for this model

Your inquiry arrives pre-filled with this model name and code, so nothing is lost in translation.

Visi Cooler 400 · EVC-400
