Product gallery

Chillers · Triple Door

Visi Cooler 1500

The largest visi cooler: 1,500 L across three doors, built for distribution depots.

Model code: EVC-1500Energy class: C

Gross capacity
1,500L
Temperature range
0…8°C
Annual energy consumption
1,764kWh/year
Warranty
60mo
Request a Quote

The cabinet

Overview

Specified for depots and cash-and-carry floors where product is held chilled in volume and moved in cases. Heavier castors, a reinforced base and a deeper cabinet than the 1200.

Doors
3
Refrigerant
R290
Dimensions (W × D × H)
1980 × 860 × 2100 mm
Net capacity
1392 L
Climate class
4 (30 °C / 55% RH) · Gulf option 43 °C / 65% RH
Warranty
12/60 mo

Annual consumption measured over a standard 24-hour duty cycle at 25°C ambient.

Features and benefits

  1. 01Case-handling depthAn 860 mm depth takes two case rows per shelf, which halves restocking time in a depot.
  2. 02Depot-grade castorsBraked 125 mm castors on a reinforced base so the cabinet can be repositioned loaded.
  3. 03Highest capacity in the range1,392 L net in a single chassis, with the same controller and parts list as the 300 L model.

Technology in this model

  • EMMD demand-matched controlCompressor speed tracks real cooling load, returning up to 20% energy savings against a fixed-speed unit.
  • Full-height LED illuminationVertical LED bars lift shelf-level brightness while drawing a fraction of a fluorescent load.
  • R290 hydrocarbon refrigerantLow-GWP charge in series production, more than 99% below an equivalent R404A circuit.
  • Low-E double glazingHeated perimeter glazing keeps the door clear at 65% relative humidity, so product stays visible.
  • Keyed door lockFitted as standard for unattended, staff-area and overnight placement.
  • Braked castorsThe cabinet can be repositioned loaded, and moved for cleaning without emptying.
  • Digital controllerLockable set point with fault-code readout for first-line diagnosis before a visit is booked.

Full specification

Specifications are nominal and measured at 25°C ambient. Tolerances and market-specific variants are confirmed on quotation.

Request a QuoteDownload ManualDownload Brochure

Capacity & dimensions

Visi Cooler 1500 EVC-1500 — Full specification — Capacity & dimensions
Gross capacity1500 L
Net capacity1392 L
Dimensions (W × D × H)1980 × 860 × 2100 mm
Net weight287 kg
Doors3 doors
Shelves10 adjustable wire shelves, 2 columns

Energy & lighting

Visi Cooler 1500 EVC-1500 — Full specification — Energy & lighting
Energy classEnergy class: C
Annual energy consumption1764 kWh/year
LightingLED canopy and full-height side LED

Cooling system

Visi Cooler 1500 EVC-1500 — Full specification — Cooling system
RefrigerantR290
Temperature range0 … 8 °C
Climate class4 (30 °C / 55% RH) · Gulf option 43 °C / 65% RH
DefrostAdaptive, demand-triggered
ControllerEMMD demand-matched digital controller

Power & support

Visi Cooler 1500 EVC-1500 — Full specification — Power & support
Power supply220–240 V / 50 Hz
Noise level49 dB(A)
Warranty12 / 60 months

Request a quote for this model

Your inquiry arrives pre-filled with this model name and code, so nothing is lost in translation.

Visi Cooler 1500 · EVC-1500
